Product Description:
Pneumatic Fittings Overview
Pneumatic fittings serve as crucial components within pneumatic
systems, facilitating the connection of different parts like pipes,
hoses, and valves.
Key Features
Types:
- Straight Fittings: These fittings are utilized to link two hoses or pipes in a
straight line.
- Elbow Fittings: Designed to alter the airflow direction, usually at a 90-degree
angle.
- Tee Fittings: Enable the airflow to branch into two directions.
- Reducer Fittings: Connect hoses or pipes of varying diameters.
Materials:
Common materials for pneumatic fittings include brass, plastic, and
stainless steel, selected based on factors like pressure rating,
chemical compatibility, and environmental conditions.
Thread Types:
Fittings are available with various thread types, such as NPT
(National Pipe Tapered) or BSP (British Standard Pipe), ensuring
secure connections.
Technical Parameters:
| Technical Parameter | Value |
|---|
| Operating Temperature | -10 ℃ - 80 ℃ |
| Working Medium | Air, Vacuum |
| Port Size | G1/8; G1/4; G3/8; G3/4; G1/2 |
| Max Pressure | 10.20Kgf/cm² |
| Thread | 1/8”~1/2” PT, G, NPT, Metric Thread |
| Maximum Pressure | 100 PSI |
| Shape | Straight |
| Connection Type | Push-to-Connect |
| Tube Size | G1/8; G1/4; G3/8; G3/4; G1/2 |
| Colour | Black, gray, blue |
Applications:
Applications
Industrial Automation: Employed in machinery and equipment to regulate actuators and
cylinders.
Packaging and Food Processing: Guarantees smooth functioning of pneumatic conveyors and
actuators.
Automotive: Applied in air brake systems, paint spraying, and various
pneumatic tools.
Robotics and Assembly Lines: Facilitates motion and control in automated systems.
Customization:
Product Customization Services for the Pneumatic Tube Fittings
Brand Name: PRIUS, XINYI or OEM
Place of Origin: China
Minimum Order Quantity: 50pc
Price: negotiable
Packaging Details: standard packaging
Delivery Time: negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000000pcs per month
Colour: Black, gray, blue
Max Pressure: 10.20Kgf/cm²
Working Temp: -10 ℃ - 80 ℃
Tube Size: G1/8; G1/4; G3/8; G3/4; G1/2
Working Medium: Air, Vacuum
Support and Services:
Our Product Technical Support team for Pneumatic Tube Fittings is
dedicated to providing assistance with installation,
troubleshooting, and maintenance of our products. We offer expert
advice and guidance to ensure that your pneumatic systems operate
efficiently and effectively.
In addition to technical support, we also provide a range of
services for Pneumatic Tube Fittings, including product training,
customization, and on-site assistance. Our team is committed to
delivering high-quality services to meet your specific needs and
requirements.
Packing and Shipping:
Product Name: Pneumatic Tube Fittings
Description: High-quality pneumatic tube fittings for various
industrial applications.
Package Includes: - 10 pieces of pneumatic tube fittings -
Instruction manual
Shipping Information: - Shipping method: Standard shipping -
Estimated delivery time: 3-5 business days - Shipping cost:
Calculated at checkout
FAQ:
Q: What are the available brand options for the Pneumatic Tube
Fittings?
A: The Pneumatic Tube Fittings are available in PRIUS, XINYI, or
OEM brands.
Q: Where is the Pneumatic Tube Fittings product manufactured?
A: The Pneumatic Tube Fittings are manufactured in China.
Q: What is the minimum order quantity for the Pneumatic Tube
Fittings?
A: The minimum order quantity for the Pneumatic Tube Fittings is 50
pieces.
Q: What are the accepted payment terms for purchasing Pneumatic
Tube Fittings?
A: The accepted payment terms for purchasing Pneumatic Tube
Fittings include L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
Q: What is the supply ability per month for the Pneumatic Tube
Fittings?
A: The supply ability for the Pneumatic Tube Fittings is 5,000,000
pieces per month.
